The KKS50 is a compact but extremely powerful, line array bass system comprised of 4 x 4” neodymium transducers engineered for maximum linear excursion and minimum residual noise, housed in a military spec. stainless steel chassis. It can be configured horizontally or vertically.
With a frequency range of 60Hz to 300Hz, the KKS50 is a companion to any of the K-array Commercial Series and Installation Series speakers, as well as the KJ50vb variable beam floor monitor. The combination provides full-range frequency response with prodigious output and a virtually invisible profile. A variety of accessories provide numerous mounting options for permanent and portable installations.
KA series amplifiers have presets specifically optimized for KKS50 applications.
Features:
- Speaker power handling: 300 W (AES)
- Max power: 400 W
- Impedance: 8 Ω or 32 Ω (selectable)
- Frequency range: 60 Hz – 300 Hz
- SPL 1W/1mt: 92 dB
- Maximum SPL: 117 dB continuous (123 dB peak)
- Crossover type: External crossover required (300 Hz low pass, 24 db/oct)
- Transducers: 4 x 4” neodymium 1.5” voice coil
- Connectors: 2 x speakON NL4
- Dimensions: 50 x 10.9 x 20.2 cm (19.69” x 4.29” x 7.95”)
- Weight: 7.6 Kg (16.76 lbs)
Recommended Amplifiers:
- 32 Ω: KA10, KA10-10, KA40 (for up to 8 X KKS50/channel) (with dedicated preset)
- 16 Ω: KA7, KA7-7, KA10, KA10-10, KA40 (with dedicated preset)
For more information, please contact phill.chapman@deltalive.com
